1.Production introduction:
DEUTZ series diesel generator set is recommended specially by our company, whose engine was jointly invested and produced by WEIFANG Diesel Engine Plant,by introducing the technology of DEUTZ,which is the producer of the first intern al-combustion engine in the world.DEUTZ company was set up in 1864,it is one of the first class manufactures of diesel engine in the world,with wide variety of power rates for the engines,now producing full range of the products,such as engines of air cooling,water cooling and fuel engines.Among its product mix,the first brand is air-cooling diesel engine.
2.Parameters of DEUTZ diesel generator set:
Model Number |
Ootput Power | Engine Type |
Cylinder Number |
Displacement (L) |
Piston Stroke (mm) |
Compression Ration |
Fuel Consumption (g/kw.h) |
Overall Dimensions L *W*H (mm) |
Weight (kg) |
|
(KW) | (KVA) | |||||||||
WET-50 | 50 | 62.5 | WP4D66E200 机械 | 4 | 4.5 | 105×130 | 18:1 | ≤205 | 2000×838×985 | 850 |
WET-75 | 75 | 93.75 | WP4D100E200 机械 | 4 | 4.5 | 105×130 | 18:1 | ≤205 | 2100×838×1033 | 950 |
WET-100 | 100 | 125 | WP6D132E200 机械 | 6 | 6.75 | 105×130 | 18:1 | ≤210 | 2100×838×1300 | 1280 |
WET-120 | 120 | 150 | WP6D152E200 机械 | 6 | 6.75 | 105×130 | 18:1 | ≤210 | 2250×838×1318 | 1380 |
WET-120 | 120 | 150 | WP6D152E200 电子 | 6 | 6.75 | 105×130 | 18:1 | ≤210 | 2250×838×1318 | 1450 |
WET-150 | 150 | 187.5 | WP10D200E200 机械 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2350×935×1480 | 1550 |
WET-150 | 150 | 187.5 | WP10D200E200 电调 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2350×935×1480 | 1650 |
WET-200 | 200 | 250 | WP10D238E200 机械 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2450×975×1475 | 1900 |
WET-200 | 200 | 250 | WP10D238E200 电子 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2450×975×1475 | 1900 |
WET-220 | 220 | 275 | WP10D264E200 机械 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2600×975×1575 | 2150 |
WET-220 | 220 | 275 | WP10D264E200 电子 | 6 | 9.726 | 126×130 | 17:1 | ≤210 | 2600×975×1575 | 2250 |
WET-250 | 250 | 312.5 | WP12D317E200 机械 | 6 | 11.596 | 126×155 | 17:1 | ≤210 | 2800×935×1680 | 2300 |
WET-250 | 250 | 312.5 | WP12D317E200 电子 | 6 | 11.596 | 126×155 | 17:1 | ≤210 | 2800×935×1680 | 2500 |
WET-300 | 300 | 375 | WP13D385E200 机械 | 6 | 12.54 | 127×165 | 17:1 | ≤210 | 3000×1100×1689 | 2760 |
WET-300 | 300 | 375 | WP13D385E200 电子 | 6 | 12.54 | 127×165 | 17:1 | ≤210 | 3000×1100×1689 | 2960 |
3.Note: The parameters listed above are for reference only and should not be taken as the basis for orders.
We also accept all kinds of special orders.
