1.Production introduction:
Shangchai diesel engine co.,Ltd. is the earliest manufacturer specialized in the production of 135 series diesel engines and the medium power diesel engines produced take a leading place in performances in the company.Its trademark "Dongfeng" is recognized tobe a "well-known brand in China".
2.Parameters of Shangchai generator set:
Model Number | Ootput Power | Engine Type | Cylinder Number | Displacement (L) | Piston Stroke (mm) | Compression Ration | Fuel Consumption (g/kw.h) | Overall Dimensions L *W*H (mm) | Weight (kg) | |
(KW) | (KVA) | |||||||||
WET-55 | 55 | 68.75 | SC4H95D2 | 4 | 4.3 | 105/124 | 17.3:1 | ≤205 | 2000×850×1427 | 800 |
WET-75 | 75 | 93.75 | SC4H115D2 | 4 | 4.3 | 105/124 | 17.3:1 | ≤205 | 2100×880×1427 | 880 |
WET-100 | 100 | 125 | SC4H160D2 | 4 | 4.3 | 105/124 | 16:1 | ≤195 | 2100×880×1527 | 1000 |
WET-120 | 120 | 150 | SC4H180D2 | 4 | 4.3 | 105/124 | 16:1 | ≤195 | 2100×880×1327 | 1200 |
WET-128 | 128 | 160 | SC8D220D2 | 6 | 6.5 | 105/124 | 16:1 | ≤195 | 2200×1000×1627 | 1300 |
WET-150 | 150 | 187.5 | SC7H230D2 | 6 | 6.5 | 105/124 | 16:1 | ≤195 | 2450×1000×1627 | 1580 |
WET-150 | 150 | 187.5 | SC7H250D2 | 6 | 6.5 | 105/124 | 16:1 | ≤195 | 2450×1000×1627 | 1680 |
WET-200 | 200 | 250 | SC8D280D2 | 6 | 8.27 | 114/135 | 18:1 | ≤195 | 2600×1100×1190 | 1740 |
WET-250 | 250 | 312.5 | SC9D340D2 | 6 | 8.82 | 114/144 | 18:1 | ≤195 | 3200×762×1190 | 1740 |
WET-300 | 300 | 375 | SC12E460D2 | 6 | 11.8 | 128/153 | 17:1 | ≤198 | 3200×1200×1707 | 1080 |
WET-300 | 300 | 375 | SC15G500D2 | 6 | 14.16 | 135/165 | 15.5:1 | ≤200 | 3200×1250×1700 | 2700 |
WET-600 | 600 | 750 | SC27G830D2 | 12 | 26.6 | 135/155 | 16:1 | ≤210 | 3700×1250×1872 | 4500 |
WET-650 | 650 | 812.5 | SC33W990D2 | 12 | 32.8 | 180/215 | 16:1 | ≤215 | 4500×1515×1889 | 6200 |
3.Note: The parameters listed above are for reference only and should not be taken as the basis for orders.
We also accept all kinds of special orders.
