1.Production introduction:
Walter - Deutz marine series, engine is selected from Weifang Weichai Deutz Diesel Engine Co., Ltd. Weichai Deutz is a joint venture products between German Deutz and China Weichai Group, mainly produces WP4 WP6 series of Deutz brand engines, Germany Deutz is a world-class diesel engine manufacturer, founded in 1864, created by the inventor of the four-stroke gas engine, Mr. Otto and Langen. Through continuous improvement and validation of 130 years , DEUTZ has become one of the world's largest diesel engine manufacturer in the world. DEUTZ engine with its excellent design, excellent quality and variety of the flexibility broadly successful in the engine area
2.The parameters of DEUTZ Silent Generator Sets:
| Model Number | Ootput Power | Engine Type 1500r/min | Bore/Stroke mm | Number of cylinders | Displacement (L) | Generator Model | Open frame Dimension L ×W×H (mm) | Weight (kg) | |
| (KW) | (KVA) | ||||||||
| CCFJ50 | 58 | 72.5 | WP4CD58E200/201 | 105/130 | 4 | 4.5 | UCM 224F | 2080×770×1200 | 1100 |
| CCFJ75 | 86 | 107.5 | WP4CD86E200/201 | 105/130 | 4 | 4.5 | UCM 274D | 2210*770*1370 | 1230 |
| CCFJ100 | 115 | 143.75 | WP6CD115200/201 | 105/130 | 6 | 6.75 | UCM 274E | 2380*800*1370 | 1650 |
| CCFJ120 | 138 | 172.5 | WP6CD138E200/201 | 105/130 | 6 | 6.75 | UCM 274G | 2400*800*1750 | 1700 |
| CCFJ150 | 173 | 216.3 | WP10CD173E200/201 | 126/130 | 6 | 9.726 | UCDM 274J | 2850*1000*1750 | 2850 |
| CCFJ180 | 207 | 258.75 | WP10CD207E200/201 | 126/130 | 6 | 9.726 | UCDM274K | 2850*1000*1750 | 2850 |
| CCFJ200 | 230 | 287.5 | WP10CD230E200/201 | 126/130 | 6 | 9.726 | HCM 4E | 2850*1000*1750 | 3050 |
| CCFJ250 | 288 | 360 | WP12CD288E200/201 | 126/155 | 6 | 11.596 | HCM4E | 2900*1000*1750 | 3180 |
| CCFJ300 | 345 | 431.25 | WP13CD345E200/201 | 127/165 | 6 | 12.54 | HCM5E | 3150*1000*1950 | 3750 |
| CCFJ350 | 403 | 503.75 | 6M26CD403E200/201 | 150/150 | 6 | 15.9 | HCM5D | 3200*1000*1950 | 3860 |
| CCFJ350 | 403 | 503.75 | 6M33CD403E200/201 | 150/190 | 6 | 20.16 | HCM5D | 3200*1000*1950 | 3860 |
| CCFJ400 | 460 | 575 | 6M26CD460E200/201 | 150/150 | 6 | 15.9 | HCM5E | 3250*1000*1950 | 3970 |
| CCFJ400 | 460 | 575 | 6M33CD460E200/201 | 150/190 | 6 | 20.16 | HCM5E | 3250*1000*1950 | 3970 |
| CCFJ500 | 575 | 718.75 | 6M33CD575E200/201 | 150/190 | 6 | 20.16 | LVM634B | 3950*1000*1950 | 6200 |
| CCFJ600 | 690 | 862.5 | 12M26CD690E200/201 | 150/150 | 12 | 31.8 | HCM6H | 4150*1000*1950 | 6200 |
| CCFJ700 | 805 | 1006.3 | 12M26CD805E200/201 | 150/150 | 12 | 31.8 | LVM634D | 4150*1500*2460 | 8350 |
| CCFJ800 | 920 | 1150 | 12M26CD920E200/201 | 150/150 | 12 | 31.8 | LVM634F | 4150 1500 2600 | 8890 |
| CCFJ800 | 920 | 1150 | 12M33CD920E200/201 | 150/190 | 12 | 40.32 | LVM634F | 4150 1500 2600 | 8890 |
| CCFJ900 | 1035 | 1293.8 | 12M33CD1035E200/201 | 150/190 | 12 | 40.32 | LVM634F | 4150 1500 2460 | 8890 |
3.Note: The parameters listed above are for reference only and should not be taken as the basis for orders. We also accept all kinds of special orders.
